Jiangxi Blueray Mechanical & Electrical Equipment Co., Ltd
one-stop design & production & installation service of packaging equipment and feed equipment supplier
| Place of Origin: | Jiangxi, China |
|---|---|
| Brand Name: | BlueRay |
| Certification: | CMC |
| Model Number: | DCS-2T/D |
| Minimum Order Quantity: | 1 Piece/Pieces |
| Price: | $5,000.00 - $25,000.00 / Piece |
| Packaging Details: | 1.normally packing in wooden cases(FCL, 20 feet container). 2. If any special requirements ,we will pack it as requested. |
| Supply Ability: | 100 Piece/Pieces per Month semi-automatic vertical packing machine |
| Dimension(L*W*H): | 1800*1800*3372mm | Lifetime: | More Than 10 Years |
|---|---|---|---|
| Application: | Powder Packing, Chemical, Commodity, Food, Machinery & Hardware, Textiles | Color: | Adjustable |
| Function: | Filling/sewing/weighing | Usage: | Granule Or Powder |
| Material: | Carbon Steel Or Stainless Steel304 | Packing Speed: | 20~40 Bags |
| Warranty: | 1 Year | Working Process: | Automatic |
| Advantage: | High Precision | Weight: | About 1 T |
| After-sales Service Provided: | No Overseas Service Provided | Packaging Type: | Bags, Cartons |
| Power: | About 3KW | Condition: | New |
| Packaging Material: | Wood | Driven Type: | Electric |
| Voltage: | 220V/380V(Three Phase Four Line) | Automatic Grade: | Semi-automatic |
| Type: | Other | Port: | Shanghai Or Any Port In China |
| Highlight: | 0.5 Ton Bagging Machine,two Ton Bagging Machine,Graphite Ton Bagging Machine |
||
♦Parameter
|
Applicable |
powder |
Rated Weighing |
0.5~2T/bag |
|
Display Resolution |
100g |
Weighing Speed |
10~20bag/hour |
|
Precision |
0.1‰~2 ‰ |
Measurement |
1800*1800*3900mm(L*W*H) |
|
Material |
stainless steel 304 In contact parts |
Host Height |
Approx.4000mm |
|
Air Source |
0.5~0.7MPa |
Power |
approx. 3kw |
|
Temperature |
-10~40℃ |
Voltage |
AC220V/AC380V/50HZ |
♦Main configuration of packing machine
| Item | main parts | Brand |
| packing machine | sensor | KELI( Ningbo) |
| PLC controller | OMRON(Japan) | |
| Cylinder | AIRTAC(Taiwan) | |
| Frequency conversion controller | DELTA(Taiwan) | |
| weighing control instrument | CHIMEI(Hongkong) | |
| Touch screen | DELTA(Taiwan) |
♦Working principle
material is fed by gravity-type feeder,and material will enter into weighing system uniformly throungh gravity-type feeder from stock bin or production line.The gravity-type feeder starts to run after turning on packing machine and then material will be filled into weighing hopper,through weighing hooper filled into bag.When weight reaches the preset value,the gravity-type feeder will stop,running.Operators takes filled bag away,or put it on belt conveyor to sewing machine.The packing process finishes.
1, Warranty:One year
We provide warranty service within a year
2, Free replacement of damaged machine parts
If the machine parts was damaged machine, please return the damaged component.
Our company will replace it with a new one, and resend it to you without charge.
3,Remote technical guidance
If there is anything wrong during the use process, please contact us straightway in phone or other communication. We surely offer you the guidance of dealing the matter.
4, Oversea Service
If there is necessary for oversea service, the engineer should be dispatched to the buyer site.
Our engineer offer service of Machine Commissioning Guidance & Operator Training for Your Staff
• Cost effective:
The configuration of our product as PLC controller, Cylinder, frequency conversion controller, weighing control instrument, sensors used international brand, such as OMRON(Japan),AIRTAC(Taiwan),DELTA(Taiwan),CHIMEI(Hongkong)and so on.
•Certification: China Metrology Certification(CMC),The only one company got the certification in JiangXi provice.
•Member:We are members of China Feed Industry Association.
•Rich experience:We have more than five years of sales experience.
•Unique design for customer :We have a strong R&D team.we can provide our customer with integral packaging system design.
•Best service:We are sure of any of your inquiry will get our prompt reply.
•Commercial principles:We keep Win-Win principle with our customer.
